722C General Purpose Baratron Absolute Capacitance Manometer, Pressure Range 10 Torr, VCR 4 Vacuum Fitting, 9-Pin Type D Connector, PN 722C11TCD2FA.
Today’s process environments require small-sized pressure measurement instruments that provide accurate, repeatable, and reliable measurements at a lower cost. MKS has applied its expertise in capacitance manometer design and manufacturing technology to the development of the compact, 722C general purpose absolute Baratron® capacitance manometer. The flexible design of the 722C makes it an ideal solution for retrofit applications as well as new equipment designs. Robust sensor construction provides high overpressure tolerances, reducing errors caused by occasional line pressure spikes. All sensor wetted surfaces are made from Inconel® to ensure maximum compatibility with many process gases1. Sophisticated technology and strict process controls ensure clean, smooth finishes (=10 Ra) on all wetted surfaces. Signal conditioning circuitry is assembled using the latest techniques in surface mount technology. All transducers are backed with a full two-year warranty.
These listing is for an MKS Type 722C general purpose capacitance manometers having a 9-pin D-subminiature signal connector, a 10 Torr full scale maximum vacuum pressure reading value, a VCR 4 female vacuum flange connection, and have MKS part number 722C11TCD2FA.
