Fabricated and assembled entirely in our manufacturing facility, these robust, inexpensive vacuum chambers are a highly efficient way for your R&D lab to get into high vacuum applications. With an internal dimension of at least 20x20x20 inches, all of these cubic chambers are made with 6061-T6 Aluminum plate. These leak-tested chambers are internally TIG welded, and include an O-ring seal, sturdy hinged door, and easy open latch for quick access. Your choice of door includes an inexpensive aluminum door, a stainless steel door for chemical resistance, a clear acrylic door for direct viewing, and aluminum or stainless steel door with a built-in viewing port. The depth of the chamber can be customized as well to meet your needs allowing for a deeper chamber with the same door size. For more custom options please call.
| 20" CHAMBER SPECIFICATIONS | |
| Interior Chamber Size | Approximately 20x20x20 inches (approx. 51x51x51cm) |
| Custom Depth | Chamber Depth Can Be Selected Between 6-48 inches Deep With Added Cost |
| Chamber Material | 6061-T6 Aluminum |
| Weight | 280 lbs (127 kg) w/o door |
| Volume | 4.8 cu. ft. (137.3 liters) |
| Hinged Front Door | Aluminum, Stainless Steel, Acrylic or Built-in Viewing Port |
| Ultimate Pressure | 1x10-6 Torr (High Vacuum) |
| Leak Tested | (Helium) to 1x10-8 atm cc/sec |
| Operating Temperature Range (Viton Seal) | 5° to 302°F (-15° to 150°C) |
| Lead Time | 8 Weeks |
| Call for additional porting options or for expanded temperature range | |
